一、LY双管液下泵概述

LY型双管液下泵是一种立式离心泵，适用于化工﹑石油﹑电力﹑冶金﹑制药﹑造纸﹑环保等多个行业部门，可用来进行对有腐蚀性液体，含有一定量固体颗粒液体的输送。是我厂选用国内优秀的水力模型设计而成,高效节能稳定是LY液下泵的优点。

LY/LYO/LYG系列长轴液下泵，选用国际优秀的水力模型，泵设计和制造按AP1610VS4型执行，泵轴由泵盖和滑动轴承体内的滑动轴承支承，上轴承采用耐磨轴承，采用锂基润滑脂润滑。该系列泵适用于输送各种腐蚀性液体和清水，同时也适用于输送含有颗粒或纤维的各类污水。LY/LYO型其输送介质温度范围为-20℃~+120℃，LYG型输送介质可达+400℃，工作压力可达1.6MPa。

二、LY双管液下泵结构特点

1.LY型长轴液下泵接轴结构安全可靠

2. 转子部件可以轴向调整

3.转子部件采用多点支撑，泵运转安全可靠。

4.滑动轴承采用外润滑或自润滑

5.泵起动时，叶轮已浸没在介质中，因而起动容易，不存在排气抽空问题

6.采用双端蜗壳泵体（口径80mm上），转子部件受径力小，轴挠度小，滑动轴承磨损小，寿命长。

7.从电机端看，泵为顺时针方向旋转。

三、LY双管液下泵型号意义

LY40-160

LY--双管长轴液下泵

40--出口直径mm

160--叶轮名义直径mm

YL型长轴立式排水泵

产品信息

产品介绍

详细规格

产品选型（）

补充说明

联系信息

还有疑问？

NO.	型号	流量 (m³/h)	H (m)	N (r/min)	P (kw)	η (%)
1	50YL(T)-10	15	10	2840	1.5	50
2	50YL(T)2-20	15	20	2870	3	50
3	50YL(T)3-30	15	30	2890	4	50
4	50YL(T)4-40	15	40	2900	5.5	50
5	50YL(T)5-50	15	50	2900	7.5	50
6	50YL(T)6-60	15	60	2930	11	50
7	50YL(T)7-70	15	70	2930	11	50
8	50YL(T)8-80	15	80	2930	11	50
9	50YL(T)9-90	15	90	2930	15	50
10	50YL(T)10-100	15	100	2930	15	50
11	50YL(T)-10-X	15	10	2840	1.5	50
12	50YL(T)2-20-X	15	20	2870	3	50
13	65YL(T)-10	30	10	2840	2.2	55
14	65YL(T)2-20	30	20	2890	4	55
15	65YL(T)3-30	30	30	2900	7.5	55
16	65YL(T)4-40	30	40	2930	11	55
17	65YL(T)5-50	30	50	2930	11	55
18	65YL(T)6-60	30	60	2930	15	55
19	65YL(T)7-70	30	70	2930	15	55
20	65YL(T)8-80	30	80	2930	18.5	55
21	65YL(T)9-90	30	90	2930	18.5	55
22	65YL(T)10-100	30	100	2940	22	55
23	65YL(T)-10-X	30	10	2840	2.2	55
24	65YL(T)2-20-X	30	20	2890	4	55
25	80YL(T)-15	50	15	2900	5.5	60
26	80YL(T)2-30	51	30	2930	11	60
27	80YL(T)3-45	52	45	2900	15	60
28	80YL(T)4-60	53	60	2940	22	60
29	80YL(T)5-75	54	75	2950	30	60
30	80YL(T)6-90	55	90	2950	30	60
31	80YL(T)7-105	56	105	2950	37	60
32	80YL(T)-15-X	50	15	2900	5.5	60
33	100YL(T)-15	80	15	2900	7.5	65
34	100YL(T)-30	81	30	2930	15	65
35	100YL(T)2-60	82	60	2950	30	65
36	100YL(T)3-90	83	90	2970	45	65
37	100YL(T)4-120	84	120	2970	55	65
38	100YL(T)-15-X	80	15	2900	7.5	65
39	100YL(T)-30-X	81	30	2930	15	65
40	150YL(T)-20	150	20	1460	15	73
41	150YL(T)2-30	151	30	1470	22	72
42	150YL(T)2-40	152	40	1470	30	73
43	150YL(T)3-60	153	60	1480	45	72
44	150YL(T)4-80	154	80	1480	55	72
45	150YL(T)5-100	155	100	1480	75	72
46	150YL(T)6-120	156	120	1480	90	72
47	150YL(T)-20-X	150	20	1460	15	73
48	150YL(T)2-30-X	151	30	1470	22	72
49	150YL(T)2-40-X	152	40	1470	30	73
50	200YL(T)-15	300	15	1470	22	75
51	200YL(T)-20	301	20	1470	30	75
52	200YL(T)2-30	302	30	1480	45	75
53	200YL(T)2-40	303	40	1480	55	75
54	200YL(T)3-65	304	65	1480	90	74
55	200YL(T)4-90	305	90	1480	110	73
56	200YL(T)-15-X	300	15	1470	22	75
57	200YL(T)-20-X	301	20	1470	30	75
58	200YL(T)2-30-X	302	30	1480	45	75
59	200YL(T)2-40-X	303	40	1480	55	75
60	250YL(T)-20	450	20	1480	45	76
61	250YL(T)2-30	451	30	1480	75	74
62	250YL(T)2-40	452	40	1480	90	76
63	250YL(T)2-50	453	50	1480	110	76
64	250YL(T)3-60	454	60	1490	132	75
65	250YL(T)3-75	455	75	1490	160	75
66	250YL(T)4-95	456	95	1480	200	74
67	250YL(T)-20-X	450	20	1480	45	76
68	250YL(T)2-30-X	451	30	1480	75	74
69	250YL(T)2-40-X	452	40	1480	90	76
70	300YL(T)-6	700	6	970	22	72
71	300YL(T)-8	700	8	980	30	72
72	300YL(T)-10	700	10	980	37	74
73	300YL(T)-15	650	15	1480	45	75
74	300YL(T)-20	650	20	1480	55	77
75	300YL(T)2-30	650	30	1490	90	76
76	300YL(T)2-40	650	40	1490	110	76
77	300YL(T)3-60	650	60	1490	185	75
78	300YL(T)4-80	650	80	1490	220	75
79	300YL(T)-6-X	700	6	970	22	72
80	300YL(T)-8-X	700	8	980	30	72
81	300YL(T)-10-X	700	10	980	37	74
82	300YL(T)-15-X	650	15	1480	45	75
83	300YL(T)-20-X	650	20	1480	55	77
84	300YL(T)2-30-X	650	30	1490	90	76
85	300YL(T)2-40-X	650	40	1490	110	76
86	350YL(T)-4	1000	4	1470	22	74
87	350YL(T)-6	1000	6	1470	30	75
88	350YL(T)-8	1000	8	1470	37	75
89	350YL(T)-10	1000	10	1470	45	76
90	350YL(T)-15	900	15	1480	75	77
91	350YL(T)-20	900	20	1490	90	78
92	350YL(T)2-30	900	30	1490	132	77
93	350YL(T)2-40	900	40	1490	160	78
94	350YL(T)3-60	900	60	1490	250	77
95	350YL(T)4-80	900	80	1490	315	77
96	350YL(T)-4-X	1000	4	1470	22	74
97	350YL(T)-6-X	1000	6	1470	30	75
98	350YL(T)-8-X	1000	8	1470	37	75
99	350YL(T)-10-X	1000	10	1470	45	76
100	350YL(T)-15-X	900	15	1480	75	77
101	350YL(T)-20-X	900	20	1490	90	78
102	350YL(T)2-30-X	900	30	1490	132	77
103	350YL(T)2-40-X	900	40	1490	160	78
104	400YL(T)-4	1500	4	1470	30	75
105	400YL(T)-6	1500	6	1470	45	77
106	400YL(T)-8	1500	8	980	55	80
107	400YL(T)-10	1500	10	980	75	80
108	400YL(T)-13	1500	13	1470	90	78
109	400YL(T)-16	1500	16	1480	110	78
110	400YL(T)-20	1250	20	1490	110	80
111	400YL(T)-25	1250	25	1490	132	80
112	400YL(T)-30	1250	30	1490	160	80
113	400YL(T)-35	1250	35	980	220	80
114	400YL(T)2-40	1250	40	1490	200	80
115	400YL(T)2-50	1250	50	1490	280	80
116	400YL(T)2-60	1250	60	1490	315	80
117	400YL(T)-4-X	1500	4	1470	30	75
118	400YL(T)-6-X	1500	6	1470	45	77
119	400YL(T)-8-X	1500	8	980	55	80
120	400YL(T)-10-X	1500	10	980	75	80
121	400YL(T)-13-X	1500	13	1470	90	78
122	400YL(T)-16-X	1500	16	1480	110	78
123	400YL(T)-20-X	1250	20	1490	110	80
124	400YL(T)-25-X	1250	25	1490	132	80
125	400YL(T)-30-X	1250	30	1490	160	80
126	400YL(T)2-40-X	1250	40	1490	200	80
127	500YL(T)-4	2200	4	980	37	82
128	500YL(T)-6	2200	6	980	55	81
129	500YL(T)-8	2300	8	980	75	81
130	500YL(T)-10	2200	10	980	90	82
131	500YL(T)-12	2200	12	980	110	84
132	500YL(T)-15	2200	15	980	132	85
133	500YL(T)-20	2300	20	980	200	83
134	500YL(T)-25	2200	25	980	220	84
135	500YL(T)-30	2200	30	980	280	83
136	500YL(T)-35	2200	35	980	315	83
137	500YL(T)-40	2200	40	980	355	83
138	500YL(T)-4-X	2200	4	980	37	82
139	500YL(T)-6-X	2200	6	980	55	81
140	500YL(T)-8-X	2300	8	980	75	81
141	500YL(T)-10-X	2200	10	980	90	82
142	500YL(T)-12-X	2200	12	980	110	84
143	500YL(T)-15-X	2200	15	980	132	85
144	500YL(T)-20-X	2300	20	980	200	83
145	500YL(T)-25-X	2200	25	980	220	84
146	500YL(T)-30-X	2200	30	980	280	83
147	600YL(T)-4	3000	4	730	45	84
148	600YL(T)-6	3000	6	730	75	83
149	600YL(T)-8	3000	8	730	110	85
150	600YL(T)-10	3000	10	730	132	83
151	600YL(T)-12	3400	12	980	160	85
152	600YL(T)-15	3000	15	980	185	85
153	600YL(T)-20	3000	20	980	250	85
154	600YL(T)-25	3000	25	980	315	85
155	600YL(T)-30	4000	30	1480	500	84
156	600YL(T)-35	4000	35	1480	560	84
157	600YL(T)-40	3200	40	1480	560	83
158	600YLTC-15	3200	15	980	200	83
159	600YLTC-15-X	3200	15	980	200	83
160	600YLTC-20	3000	20	980	250	83
161	600YLTC-20-X	3000	20	980	250	83
162	600YL(T)-4-X	3000	4	730	45	84
163	600YL(T)-6-X	3000	6	730	75	83
164	600YL(T)-8-X	3000	8	730	110	85
165	600YL(T)-10-X	3000	10	730	132	83
166	600YL(T)-12-X	3400	12	980	160	85
167	600YL(T)-15-X	3000	15	980	185	85
168	600YL(T)-20-X	3000	20	980	250	85
169	600YL(T)-25-X	3000	25	980	315	85
170	700YL(T)-4	4500	4	730	75	83.5
171	700YL(T)-6	4500	6	730	110	84.5
172	700YL(T)-8	4500	8	730	160	82.5
173	700YL(T)-10	4500	10	730	185	83.5
174	700YL(T)-12	4500	12	730	220	83.5
175	700YL(T)-15	4500	15	980	280	85.5
176	700YL(T)-20	4500	20	980	355	86.5
177	700YL(T)-25	4500	25	980	450	85
178	700YL(T)-30	4500	30	980	560	85
179	700YLTC-15	4500	15	980	280	84
180	700YLTC-15-X	4500	15	980	280	84
181	700YLTC-20	4500	20	980	355	85.5
182	700YLTC-20-X	4500	20	980	355	85.5
183	700YL(T)-10-X	4500	10	730	185	83.5
184	700YL(T)-25-X	4500	25	980	450	85
185	700YL(T)-30-X	4500	30	980	560	85
186	800YL(T)-4	6400	4	585	110	85.1
187	800YL(T)-6	6000	6	585	160	84.8
188	800YL(T)-8	6500	8	585	220	84.5
189	800YL(T)-10	6400	10	590	250	83.5
190	800YL(T)-12	6200	12	590	315	84.3
191	800YL(T)-15	7000	15	590	450	84.5
192	800YL(T)-20	6200	20	730	500	86.5
193	800YL(T)-25	6200	25	730	600	85
194	800YL(T)-7-X	6000	7	590	185	85
195	800YL(T)-13.4-X	6700	13.4	590	355	84.8
196	800YL(T)-17-X	6000	17	590	400	84.5
197	800YLTC-15	7000	15	590	450	84
198	800YLTC-15-X	7000	15	590	450	84
199	800YLTC-20	6200	20	730	500	85.5
200	800YLTC-20-X	6200	20	730	500	85.5
201	800YL(T)-4-X	6400	4	585	110	85.1
202	800YL(T)-6-X	6000	6	585	160	84.8
203	800YL(T)-8-X	6500	8	585	220	84.5
204	800YL(T)-10-X	6400	10	590	250	83.5
205	900YL(T)-4	8500	4	485	160	85.1
206	900YL(T)-6	8500	6	485	200	85.3
207	900YL(T)-8	8000	8	490	280	84.5
208	900YL(T)-10	8000	10	590	315	84.9
209	900YL(T)-14	8000	14	590	450	85.3
210	900YL(T)-16	8000	16	590	500	85.2
211	900YL(T)-20	8000	20	590	630	86.4
212	900YL(T)-25	8000	25	590	800	85
213	900YL(T)-7-X	9000	7	490	250	85.1
214	900YL(T)-12.6-X	8000	12.6	590	450	87
215	900YL(T)-17-X	8000	17	590	560	85.5
216	900YLTC-15	8000	15	590	500	84.5
217	900YLTC-15-X	8000	15	590	500	84.5
218	900YLTC-20	8000	20	590	630	85.5
219	900YLTC-20-X	8000	20	590	630	85.5
220	1000YL(T)-4	9500	4	485	185	87
221	1000YL(T)-7	10500	7	485	315	87.1
222	1000YL(T)-9	10000	9	490	355	84.5
223	1000YL(T)-10	10000	10	490	400	85.2
224	1000YL(T)-13	10000	13	490	500	85.3
225	1000YL(T)-16	10000	16	490	630	85.6
226	1000YL(T)-18	10000	18	490	710	85.8
227	1000YL(T)-20	10000	20	490	800	86.4
228	1000YL(T)-7-X	10500	7	485	315	87.1
229	1000YL(T)-13-X	10000	13	490	500	85.3
230	1000YL(T)-17-X	10000	17	490	710	85.5
231	1000YLTC-15	9000	15	490	560	84.5
232	1000YLTC-15-X	9000	15	490	560	84.5
233	1000YLTC-20	9000	20	590	710	86
234	1000YLTC-20-X	9000	20	590	710	86
235	1200YL(T)-4	13500	4	490	250	84.2
236	1200YL(T)-6	15000	6	490	355	87.4
237	1200YL(T)-9	14500	9	490	560	84.5
238	1200YL(T)-12	14500	12	490	710	85.2
239	1200YL(T)-14	14000	14	490	800	85.3
240	1200YL(T)-16	13000	16	490	800	86.6
241	1200YL(T)-18	15000	18	495	1000	85.8
242	1200YL(T)-20	16000	20	495	1250	86.4
243	1200YL(T)-24	14000	24	495	1250	87
244	1200YL(T)-8-X	14400	8	490	450	85.4
245	1200YL(T)-10-X	14000	10	490	560	85.3
246	1200YL(T)-17-X	14000	17	490	900	86.5
247	1200YLTC-15	10000	15	490	630	84.5
248	1200YLTC-15-X	10000	15	490	630	84.5
249	1200YLTC-19	6732	19	590	500	88
250	1200YLTC-19-X	6732	19	590	500	88
251	1400YLTC-9	12816	8.5	370	400	87
252	1400YLTCB-10(-4)	8856	8.6	370	300	88.7
253	1400YLTCB-10(-2)	9792	9.2	370	355	88.8
254	1400YLTCB-10(0)	10620	10	370	400	89.1
255	1400YLTCB-10(+2)	11412	10.7	370	450	89.6
256	1400YLTCB-10(+4)	12240	11.3	370	500	89.2
257	1400YLTCQ-10	11412	10.7	370	450	89.6
258	1400YL(T)-14	18000	14.2	370	900	89
259	1400YL(T)-60	16200	60	495	3600	86
260	1400YL(T)-60A	15300	51.7	495	3000	85
261	1400YL(T)-60B	14400	44.5	495	2200	83
262	1400YL(T)-10	23400	9.7	370	800	88.4
263	1400YLTC-9-X	12816	8.5	370	400	87
264	1400YL(T)-14-X	18000	14.2	370	900	89
265	1500YLTC-26-X	16128	26.3	495	1400	88.5
266	1500YLTC-26A-X	16200	21	495	1200	88
267	1500YLTC-26B-X	15480	19.8	495	1100	87
268	1500YL(T)-26-X	16128	26.3	495	1400	88.5
269	1600YLTC-6-X	20700	6.8	495	500	87.5
270	1600YLTCQ-8	17640	8.9	333	560	87
271	1600YLTCQ-10-X	18252	9.55	370	630	88.4
272	1600YLTC-11(-4)	17640	9.5	370	630	85.5
273	1600YLTC-11(-2)	19800	9.9	370	710	87.3
274	1600YLTC-11(0)	21600	10.9	370	800	88.7
275	1600YLTC-11(+2)	22896	12	370	900	88.7
276	1600YLTC-11(+4)	24480	12.3	370	1000	87.7
277	1600YLTC-14	12024	14.6	370	630	88.8
278	1600YL(T)-7	22680	7.18	295	550	88.8
279	1600YL(T)-12	22680	11.6	333	900	88.6
280	1600YL(T)-13.5	22680	13.5	333	1100	88
281	1600YL(T)-14.6	22680	14.65	375	1200	88.8
282	1600YL(T)-20	22680	19.57	375	1500	89
283	1600YL(T)B-16(-6)	18360	12.8	330	8000	83
284	1600YL(T)B-16(-4)	20880	13.8	330	1100	85.3
285	1600YL(T)B-16(-2)	23400	14.5	330	1200	85.3
286	1600YL(T)B-16(0)	24480	16.1	330	1400	85.7
287	1600YL(T)B-16(+2)	27000	18	330	1800	86
288	1600YL(T)B-16(+4)	29880	17.2	330	1800	86.9
289	1600YL(T)-19	30600	18.75	330	2000	86
290	1600YL(T)B-15.5(-4)	28800	13.8	295	1400	88
291	1600YL(T)B-15.5(-2)	31176	14.6	295	2000	88
292	1600YL(T)B-15.5(0)	33948	15.8	295	2000	87
293	1600YL(T)B-15.5(+2)	36000	17.6	295	2500	87
294	1600YL(T)B-15.5(+4)	38340	18.4	295	2500	86.8
295	1600YLTC-40	15300	41.9	595	2500	86.9
296	1600YL(T)-7-X	22680	7.18	295	550	88.8
297	1600YL(T)-14.6-X	22680	14.65	375	1200	88.8
298	1600YL(T)-20-X	22680	19.57	375	1500	89
299	1600YL(T)-19-X	30600	18.75	330	2000	86
300	1600YLTC-40-X	15300	41.9	595	2500	86.9
301	1800YLTCQ-16	21600	16	370	1600	88
302	1800YLTC-17	20340	17.3	370	1250	88
303	1800YLTC-21	21672	21	370	1600	89
304	1800YLTC-24-X	23760	24	425	2000	87.8
305	1800YLTC-26-X	23760	26.1	495	2500	87.5
306	1800YLTC-28.5-X	21600	28.5	370	2500	87
307	1800YL(T)-34	28800	33.8	370	3600	88
308	1800YL(T)-34A	27252	29	370	3200	88
309	1800YLTC-17-X	20340	17.3	370	1250	88
